Description:
ARF stands for Almost-Ready-to-Fly,ARF planes are pre-covered and come with some key components already installed, but require additional items to be completed before flying.
Length 1400mm
Width 1600mm
Weight EP/2,550g (approx.), GP/2,450g (approx.)
Motor 600-1000W BL Motor (sold separately)
Engine 2 Cycle 40-46 class engine (sold separately)
Battery (EP) 14.8V-4,000-5,000mAh Li-Po battery (sold separately)
Main Wing Area 44dm2
Wing Loading 55.7-55.9g/dm2
Airfoil Original semi-symmetrical
Propeller size D11 x P7-D12 x P8 (sold separately)
Tire size Nose 60mm / Main 60mm
Dihedral 2.5°
Side Thrust 2°
R/C system (EP) 4ch, 4 servo, 1 ESC (sold separately)
R/C system (GP) 4ch, 5 servo (sold separately)
Set Contents
Completed fuselage with film applied
Complete set of linkage parts
Engine mount
Fuel tank
Silicon tube
Motor mount
Spinner
Main and nose gears
EP cowling
Decal
What you need to fly
EP Specifications
4-channel, 4-servo radio system for airplanes (standard servos x 4)
Battery for transmitter
100mm Y-shaped extension cord for aileron servo x 1
Two 200mm extension cords for aileron servos
Propeller
Outrunner BL motor for 40-50 class
ESC
Li-Po battery
Li-Po battery charger
GP Specifications
4-channel, 5-servo radio system for airplanes (5 standard servos)
Transmitter/receiver batteries
100mm Y-shaped extension cord for aileron servo x 1
200mm extension cord for aileron servo x 2 pcs.
Propeller
2-cycle 40-46 engine for airplane
Starting tools (plug heat, starter, starter battery, charger)
Glow fuel for airplanes
